Compact 10KW Single Phase Hybrid Solar Inverter for Home Energy Storage

Compact 10KW Single Phase Hybrid Solar Inverter for Home Energy Storage

The XD7-10KTL single-phase energy storage inverter features a compact, lightweight design, making installation simple and versatile across various setups. With a maximum string current of 20A, it supports high-power modules, and its EPS switching time is under 10ms. It is compatible with both lithium and lead-acid batteries. Additionally, it comes with a standard diesel generator interface, supporting generator and Smart load connections, making it ideal for diverse home energy storage applications.

Enecell is one of Famous Single Phase Hybrid Inverter Manufacturer and Hybrid solar inverter Supplier,The XD7-10KTL single-phase low-voltage energy storage inverter has a string current of up to 16A and is compatible with power components. It supports greater off-grid load capacity, is compatible with mainstream battery brands, and has UPS-level switching levels to ensure stable operation of key equipment. It can be used in various household energy storage application environments, with the best cost-effectiveness, to meet your dual choice of efficiency and value.

Product Advantages

Efficient & Higher Revenue

˙ Max. Efficiency 98%

˙ 2 MPP Trackers,160% DC input Oversizing

˙Max. PVinput Current 20A, Compatible with High Power Modules

˙200% Peak Output Power at EPs Mode

Intelligent & Simple O&M

˙ IP66 Protection Degree

˙ SPD Type ll:DC & AC

˙ Support AFCl Function(Optional)

˙ Support Smart l-V Curve Diagnosis Function

Flexible & Abundant Configuration

˙ EPS Switching Time<l0ms

˙ Compatible With Lithium & Lead-acid Battery

˙ Support Work in Parallel Mode

˙ Support Diesel generator& Smart Load Connection



	XD7KTL	XD8KTL	XD10KTL
Input(PV)
Max. PV Input Power	11.2kW	12.8kW	16kW
Max. PV Input Voltage	600V
Start-up Voltage	100V
MPPT Voltage Range	100V-550V
Number of MPPT Trackers	2
Number of String per MPPT	2/1
Max. PV Input Current	40/20A
Output(AC)
Rated Output Power	7kW	8kW	10kW
Max. Out Active Power	7.7kW	8.8kW	11kW
Max. Output Current	35A	40A	50A
Rated Voltage	230V
Rated Frequency	50Hz / 60Hz
THDi(@Rated Power)	<3%
Power Factor	0.8 leading~0.8lagging
Battery
Battery Type	Lithium, Lead-acid
Battery Voltage Range	40~60V
Max. Charge/Discharge Current	160A	190A	210A
Output(EPS)
Max. Output Power	7.7kVA	8.8kVA	11kVA
Max. Output Current	35A	40A	50A
Peak Output Power, Time	14kW,10s	16kW,10s	18kW,10s
Rated Voltage	230V
THDv(@Rated Power)	< 3%
Switch Time	<10ms
Efficiency
Max. Efficiency	98.00%
European Efficiency	97.50%
Battery Charge / Discharge Efficiency	97.00%
Protection
DC Reverse Polarity Protection	Yes
Insulation Resistance Monitoring	Yes
Ground Fault Monitoring	Yes
Over Current / Over Voltage Protection	Yes
Battery Soft Start Protection	Yes
AFCI Protection	Optional
Surge Protection	Type II
Communication
Display	LCD
Communication	RS485/CAN/WIFI/4G/Bluetooth
General Data
Dimension(WxHxD)	440mm*530mm*250mm
Operating Temperature Range	-30℃~+60℃
Self-consumption	<10W
Topology	High Frequency Insolation(For Battery)
Protection Degree	IP66
Relative Humidity	0~100%
Max. Operating Altitude	4000m
Cooling Method	Smart Forced Air Cooling



---
