Wall Mounted Lithium Battery Off Grid Hybrid Inverter 3kWh-5kWh 120V 100Ah Battery LiFePO₄ Solar Inverter for Home Use
Fast Charge & Discharge Rates
International standard 48V system.
USB/RS485/Wi-Fi/GRS(option)
98% Efficiency Rate
Perfect protection function of BMS
Modular, Scalable & Proven Performance
Long life cycle, >6000 times at 80% DOD
Easy to install
Environmental friendly
Perfect thermal design
Item NO. :
FM-PS2Size (mm) :
≥5Warranty :
5 YearsPower :
3-5kWhPayment :
T/TLead Time :
30 daysApplicable Scenarios :
ResidentialVoltage :
51.2VWall Mounted Lithium Battery Off Grid Hybrid Inverter 3kWh-5kWh 120V 100Ah Battery LiFePO₄ Solar Inverter for Home Use
The Energy Storage Battery Off-Grid Hybrid Inverter is a cutting-edge energy solution designed for residential use. With a 5kWh capacity, 51.2V voltage, and 100Ah LiFePO₄ (Lithium Iron Phosphate) battery, this system is ideal for solar energy storage and off-grid applications. It combines energy storage and inverter functionality in a single unit, providing a reliable, efficient, and eco-friendly power supply for homes.
Features
High Efficiency and Performance:
The LiFePO₄ battery offers excellent energy density, fast charging, and long-lasting performance.Advanced hybrid inverter technology ensures optimal energy conversion with minimal losses.
Long Lifespan:
The LiFePO₄ battery supports over 4000+ charge/discharge cycles, significantly outlasting traditional lead-acid batteries.
Off-Grid Independence:
Provides a stable and reliable power supply in off-grid environments, making it ideal for remote areas or homes seeking energy autonomy.
Cost-Effective:
Reduces electricity bills by utilizing stored solar energy and minimizing dependence on grid power.
Safe and Reliable:
Equipped with an intelligent Battery Management System (BMS) to protect against overcharging, over-discharging, overheating, and short circuits.
Compact and Integrated Design:
Combines energy storage and inverter functionality in one unit, saving space and simplifying installation.
Specifications
| Model | 3000W | 5000W |
| Rated Voltage | 51.2V | 51.2V |
| Operating Voltage | 40-58.4V | 40-58.4V |
| Rated Capacity | 60 Ah | 100 Ah |
| Energy | 3.0KWh | 5.0KWh |
| Max. Continuous Charge Current | 60A | 100A |
| Max. Continuous Discharge Current | 80A | 120A |
| Charging temperature range | 0-45℃ | 0-45℃ |
| Discharge temperature range | -10-60℃ | -10-60℃ |
| Approx. Dimension L*W*H | 793.7mm*562mm*138mm | |
| Approx. Weight | 48kg | |
| Life | 10 Years | |
| Installation form | Wall-mounted | |
| Battery BMS protection function |
Overcharge/overdischarge/overtemperature/
overcurrent/short circuit
|
Overcharge/overdischarge/overtemperature/
overcurrent/short circuit
|
| Power charging | ||
| Cycles(80%DOD 25℃) |
(170Vac~280Vac)±2%
(90Vac~280Vac)±2%
|
|
| Solar panel input voltage |
Voltage ≤145V, current ≤60A, maximum power 4200W
|
|
| AC output parameters | ||
| Output voltage | AC220V | AC220V |
| Maximum output power | Two output ports total: 3000W | Two output ports total: 5000W |
| Peak output power | 6000W/5S | 10000W/5S |
| Wave type | Sine wave | Sine wave |
| Frequency | 50Hz | 50Hz |
| Efficient | >95% | |
| LCD | ||
| Display size | 41*13mm | |
| Working power consumption | MAX8mA | |
| Standby power consumption | MAX0.5mA | |
| Sleep power consumption | MAX50uA | |
Application Case
About Us
Glory Zenith. is a high-tech enterprise focusing on the field of new energy with more than 20 years of industry experience. We are committed to providing efficient, reliable and intelligent new energy solutions to global customers, covering solar energy, energy storage, battery technology and related application fields.
With a professional scientific research team, a complete after-sales service system and advanced production capabilities, our products and services have been distributed in more than 30 countries around the world, such as the United States, the United Kingdom, etc., and have become a trusted partner of many customers.
Partnership
Our renewable energy products have been trusted and adopted by renowned partners such as China Railway Group (CREC), Midea, Haier, Poly Group, Country Garden, PetroChina, Shenling Group, and Alibaba, among others. These collaborations reflect our strong reputation, reliable product quality, and ability to deliver innovative energy solutions that meet the diverse needs of leading enterprises across various industries.
Product Certificates
High-Performance LiFePO₄ Battery Technology All-in-One Design Scalable and Modular Stackable system Seamless Solar Integration Smart Energy Management Wide Operating Temperature Range
